If your 2013 Dodge Grand Caravan (or Chrysler Town & Country) is having a "free-for-all" with its gears—slipping, failing to find 3rd or 4th, or sticking in limp mode—you’re likely dealing with a failed 62TE transmission valve body or solenoid pack.
At the dealership, this is billed as an 11-hour job. At a standard shop rate of $140/hour, you're looking at over $1,500 just in labor. Today, I’m going to show you how to knock this out in your own driveway and keep that cash in your pocket.
The "Why": Don't Fall for the "Maintenance Free" Myth
Dealerships love to tell you these transmissions are maintenance-free. As a mechanic with over 20 years of experience, I’m telling you: that’s a load of junk. No transmission fluid lasts 200,000 miles. If you don't service your filters and fluid, your valve body will eventually fail.
Tools & Parts You’ll Need
-
Transmission Valve Body/Solenoid Pack (Look for the full assembly to save time)
-
ATF+4 Transmission Fluid (Mopar recommended)
-
New Transmission Filter & Gasket
-
Sockets: 8mm, 10mm
-
Torx Bits: T25, T27
-
Extras: 6-inch extension, PB Blaster, Dielectric Grease, and Shop Rags
Step-by-Step Breakdown
1. Clear the Way
Safety first—disconnect that negative battery terminal (10mm). You’ll be working near electrical connectors, so don't skip this. To get a clear view, remove the plastic engine cover and slide the engine coolant reservoir up and out of its brackets. You don't need to disconnect the hoses; just move it to the side.
2. Accessing the Transmission Cover
The 62TE has a front-facing cover held on by a mix of 10mm studs (for the sound matting) and 8mm bolts.
-
Pro-Tip: Take your time with the gray harness clip on the solenoid pack. If you break this plastic connector, you're looking at a very expensive wiring harness repair. Use a delicate touch.
3. Removing the Valve Body
Once the cover is off, you’ll see the valve body assembly. It’s held in place by several 8mm bolts.
-
Watch the "Tubes": There are three small vacuum/oil tubes behind the valve body. When you pull the unit out, try to hold these in place with needle-nose pliers so they don't fall into the transmission pan.
-
The Detent Arm: Pay close attention to the metal pin and the detent arm at the bottom. When you reinstall, that pin needs to sit perfectly in the "fifth valley" of the gear selector.
4. The "While You're In There" Rule
If you're replacing the valve body, you have to drain the fluid anyway. This is the perfect time to drop the bottom pan, swap out the transmission filter, and put on a fresh gasket. It’s cheap insurance for your new parts.
5. Torque Specs & Reassembly
When putting the cover back on, don't just "crank" it down. The torque spec for those 8mm bolts is 51 inch-pounds (which is just under 4 foot-pounds). These are small bolts going into aluminum—don't snap them!
Check out our Full length Youtube guide here!
The Final Verdict
By doing this yourself, you just completed an "intermediate" repair that shops use to pay their rent for the month. You’ve ensured your family van is safe for the road and saved a four-figure repair bill in the process.
Ready to grab the parts? Check out the Wrench Army Shop for the diagnostic tools I use to reset transmission codes, and don't forget to Subscribe to the Sell Those Flipping Cars YouTube channel for more DIY saves.
Keep on wrenching everyone!
